Máy định vị GPSMAP® 547

Khuyến mãi và Cách thức mua hàng

CÁCH THỨC MUA HÀNG: Cách 1: Đặt hàng online chỉ với 1 click chuột ở phía dưới, chúng tôi sẽ liên hệ lại và giao hàng cho bạn trên Toàn quốc. Cách 2: Gọi Điện thoại hoặc Chat để được tư vấn và đặt hàng trực tiếp như thông tin Liên hệ phía dưới. Cách 3: Mua hàng trực tiếp tại Công ty Tín Đức. Công ty Tín Đức giao hàng tận nơi trên Toàn quốc. Khách hàng nhận hàng tại nhà và thanh toán cho người giao hàng. Khách hàng đại lý và dự án xin vui lòng gọi điện trực tiếp cho Phòng dự án để nhận được hỗ trợ tốt nhất.

Thông tin về sản phẩm

An Amazing Chartplotter

5" VGA display
10 Hz GPS/GLONASS receiver
Wireless connectivity
U.S. coastal and inland mapping

GPSMAP 547 allows for easy visibility, day or night. Whether it is flat, flush or swivel-mounted, it will be the focal point of your helm. It includes our hallmark user-friendly interface as well as U.S. coastal and inland mapping.

With the integration of a 10Hz GPS/GLONASS receiver, the 547 refreshes position and heading up to 10 times per second. It displays constant and fluid on-screen location and proves to be incredibly accurate when marking and navigating to any one of 5,000 user-created waypoints.

It also has wireless connectivity, giving you the opportunity to connect and access marine-specific apps via smartphone or tablet.

View and Control Your Device From an iPhone® or iPad®

Garmin Helm allows you to view and control your compatible Garmin chartplotter from an iPhone or iPad — while providing enhanced situational awareness for the mariner. Easily switch between portrait and landscape mode to accommodate mounting preferences. Using your Apple digital mobile device, you can even record a movie of your chartplotter screen to share with friends and family. Download from the App Store™ today.

Physical & Performance
Unit dimensions, WxHxD	5.9" x 6.1" x 2.4" (15.0 x 15.5 x 6.1 cm)
Display size, WxH	3.0" x 4.0"; 5.0" diagonal (7.6 x 10.2 cm; 12.7 cm diagonal)
Display resolution, WxH	480 x 640 pixels
Display type	VGA display
Weight	1.7 lbs (0.8 kg)
Water rating	IPX7
Receiver	10 Hz high-sensitivity
Antenna	Internal with external connection
Mounting options	Bail with swivel, flat or flush
Power consumption	Max power usage at 10 Vdc: 27 W Typical current draw at 12 Vdc: 450 mA Max current draw at 12 Vdc: 2.7 A

Maps & Memory
Preloaded maps	BlueChart® g2 (coastal maps)
Accepts data cards	2 microSD™ cards
Waypoints	5,000
Routes	100
Track log	50,000 points; 50 saved tracks

Features & Benefits
Garmin Radar compatible	No
Garmin Sonar compatible	No
NMEA 2000® compatible	Yes
NMEA 0183 compatible	Yes
Garmin Marine Network™ compatible	Yes (limited capabilities)
Garmin SmartMode compatible (customizable monitor presets)	No
Supports AIS (tracks target ships position)	Yes
Supports DSC (displays position data from DSC-capable VHF radio)	Yes
Tide tables	Yes
Garmin Meteor Audio System compatible	Yes
Supports Fusion Lync compatible marine radios	Yes
GSD™ Black Box sonar support	No
GCV™ Black Box sonar support	No
SiriusXM™ Weather & Radio compatible	Yes
BlueChart® Mobile (planning) compatible	Yes
Garmin Helm compatible	Yes
GRID™ (Garmin Remote Input Device) compatible	No
Wireless remote compatible	No
Wireless mouse compatible	No

Sonar Features & Specifications
Dual-frequency (50/200 kHz) sonar capable	No
Dual-beam (77/200 kHz) sonar capable	No
CHIRP sonar technology	No
DownVü™	No
SideVü™	No
Voltage range	10-32 Vdc input

Connections
NMEA 0183 input ports	2
NMEA 0183 output ports	2
Video input ports	None
Video output ports	None
Wireless connectivity	Yes
Garmin Marine Network™ ports	1
